The Refrigerated Microbial Growth Chamber is thoughtfully designed for laboratories that require precise temperature control along with consistent shaking performance. It combines incubation, refrigeration, and orbital shaking into a single compact system, making it highly efficient for microbiological and cell culture applications.
Built with durable materials and advanced control systems, this chamber ensures stable environmental conditions, helping researchers achieve reliable and reproducible results every time. Whether it’s routine testing or advanced research, this equipment supports smooth and uninterrupted lab operations.
Why This Product Stands Out
What makes this system truly valuable is its integrated orbital shaker inside the BOD chamber, eliminating the need for separate equipment. The independent display for RPM and temperature allows easy monitoring and precise adjustments, giving users complete control over experimental conditions.
The inclusion of data logging and PT100 sensing technology ensures accuracy, consistency, and traceability- essential for modern laboratories.
Key Features of Refrigerated Microbial Growth Chamber
Built-in orbital shaker within the chamber
Smooth speed control from 50 to 350 RPM
Separate display for RPM and temperature
High-precision PT100 temperature sensor
Independent control for temperature and shaking
Inbuilt data logging system
Strong and durable SS 304 inner chamber
Uniform temperature distribution across the chamber
User-friendly digital interface
Construction & Build Quality
The chamber is designed to last. The inner body is made of stainless steel 304, ensuring hygiene and corrosion resistance, while the outer structure is finished with powder-coated mild steel for long-term durability.
With 75 mm insulation, the system maintains temperature stability efficiently, reducing energy loss and improving performance consistency.
Performance Details
Temperature Range: 20°C below ambient to 80°C
Temperature Accuracy: ±0.1°C
Shaking Speed: 50 to 350 RPM
Speed Accuracy: ±1 RPM
Drive System: Triple-eccentric counterbalanced mechanism
Motor: AC induction motor
Built-in timer and audio-visual alarm system
Platform & Capacity
The unit comes with a universal platform (460 × 460 mm) that supports multiple flask sizes. It is designed to handle:
16 flasks of 500 ml
25 flasks of 250 ml
9 flasks of 1000 ml
4 flasks of 2000 ml
Clamps ensure that flasks remain securely in place during operation, even at higher speeds.
Included Accessories
To make the system more versatile, the following are supplied with the chamber:
Gassing manifold
Photosynthetic light bank
UV light
Culture drawers/Shelves
These additions allow the chamber to support a wider range of experimental needs without requiring extra setup.
Control & Data Monitoring
The chamber is equipped with a PT100 sensor for accurate temperature sensing. It also features:
Independent temperature control
Integrated data logger
Easy monitoring of real-time conditions
This ensures complete control over experiments and reliable documentation when required.
Applications
This system is ideal for:
Microbial culture growth
Cell culture studies
Fermentation experiments
Pharmaceutical testing
Biotechnology research
Environmental and R&D laboratories
